UID-EO200 x1

Handheld  Edible Oil ID Analyzer by Fiber Probe & Trigger


  • High sensitivity- High S/N ratio - High detection rate

  • Can test oxygen in air or 50 ppm of nitrate solution in 10 s’

  • Dark colored EO samples can be detected

  • EO Sample’s volume is no limitation


Quick ID mode in seconds

Edible Oil choose.jpg

Operation Interface-1


Operation Interface-2

Specifications

Excitation Source

NIR, Frequency Stabilized, Narrow Linewidth Diode Laser

Wavelength Accuracy:785 nm

Laser Power: 300 mw (785nm) with Laser Shutter Control
CCD Spectograph

F 1.6 High Sensitivity CCD Spectrograph

Pixel Resolution: 1.5 ㎝-1(785 nm Excitation)

Spectral Coverage: ~250~2,350 cm-1

Sensitivity and S/R Ratio

Measure Nitrate solution up to 50 ppm in 10 sec.

S/N Ratio :6,000 : 1
Dimensions 13'' x 10'' x 6''
Weight ≒ 2.5 kg
